Home / Products / Switches / Pushbutton Switches / YB215CWCSW01-5D-JS
NKK Switches YB215CWCSW01-5D-JS
- MFG Part Number
- YB215CWCSW01-5D-JS
- Available Quantity
- 35370 Pieces
- Reference Price
- USD 0
- Our Price
- We have a big discount, please contact us
- Shipping Date
- We can ship out today
- Manufacturer
- NKK Switches
- Brief Description
- YB2 SWITCH PUSHBUTTON SPDT 3A 125V
- Lead Free Status / RoHS Status
- RoHS Compliant (Lead Free)
- Moisture Sensitivity Level (MSL)
- 1 (Unlimited)
- Date Code (D/C)
- New
- Product Category
- Pushbutton Switches
- Stock Resource
- Franchised Distributor
- Warranty
- 360 days quality guarantee
- Datasheet
- YB215CWCSW01-5D-JS.pdf
YB215CWCSW01-5D-JS Specifications
| Manufacturer Part Number | YB215CWCSW01-5D-JS |
|---|---|
| Future Part Number | FT-YB215CWCSW01-5D-JS |
| SPQ / MOQ | Contact Us |
| Packing Material | Reel/Tray/Tube/Others |
| Series | YB2 |
| YB215CWCSW01-5D-JS Status (Lifecycle) | In Stock |
| Part Status | Obsolete |
| Type | Standard, Illuminated |
| Circuit | SPDT |
| Switch Function | On-Mom |
| Current Rating | 3A (AC/DC) |
| Voltage Rating - AC | 125V |
| Voltage Rating - DC | 30V |
| Actuator Type | Round, Button, Flush |
| Color - Actuator/Cap | Silver |
| Illumination Type, Color | LED, Amber |
| Illumination Voltage (Nominal) | 2 VDC |
| Mounting Type | Panel Mount, Front |
| Termination Style | Solder, Quick Connect - 0.110" (2.8mm) |
| Ingress Protection | IP65 - Dust Tight, Water Resistant |
| Features | Epoxy Sealed Terminals |
| Panel Cutout Dimensions | Circular - 22.00mm Dia |
| Operating Temperature | -25°C ~ 50°C |
| Country of Origin | USA/JAPAN/MALAYSIA/MEXICO/CN |
| YB215CWCSW01-5D-JS Weight | Contact Us |
| Replacement Part Number | YB215CWCSW01-5D-JS-FT |
