TDK Corporation VLM13580T-2R2M-D1

Name: VLM13580T-2R2M-D1
Brand: TDK Corporation
SKU: VLM13580T-2R2M-D1
Price: 3.4 USD
Availability: InStock
Rating: 4.8 (172 reviews)

MFG Part Number: VLM13580T-2R2M-D1

Available Quantity: 42870 Pieces

Reference Price: USD 3.4

Our Price: We have a big discount, please contact us

Shipping Date: We can ship out today

Manufacturer: TDK Corporation

Brief Description: VLM FIXED Inductors 2.2UH 10.5A 3.9 MOHM

Lead Free Status / RoHS Status: RoHS Compliant (Lead Free)

Moisture Sensitivity Level (MSL): 1 (Unlimited)

Date Code (D/C): New

Product Category: Fixed Inductors

Stock Resource: Franchised Distributor

Warranty: 360 days quality guarantee

Datasheet: VLM13580T-2R2M-D1.pdf

Request Quotation for VLM13580T-2R2M-D1

Company Name

Contact Person

Phone Number

Address

Email

Message

VLM13580T-2R2M-D1 Specifications

Manufacturer Part Number	VLM13580T-2R2M-D1
Future Part Number	FT-VLM13580T-2R2M-D1
SPQ / MOQ	Contact Us
Packing Material	Reel/Tray/Tube/Others
Series	VLM
VLM13580T-2R2M-D1 Status (Lifecycle)	In Stock
Part Status	Active
Type	Wirewound
Material - Core	Ferrite
Inductance	2.2µH
Tolerance	±20%
Current Rating	10.5A
Current - Saturation	20A
Shielding	Shielded
DC Resistance (DCR)	3.9 mOhm Max
Q @ Freq	-
Frequency - Self Resonant	-
Ratings	AEC-Q200
Operating Temperature	-40°C ~ 125°C
Inductance Frequency - Test	100kHz
Features	-
Mounting Type	Surface Mount
Package / Case	Nonstandard
Supplier Device Package	-
Size / Dimension	0.531" L x 0.480" W (13.50mm x 12.20mm)
Height - Seated (Max)	0.327" (8.30mm)
Country of Origin	USA/JAPAN/MALAYSIA/MEXICO/CN
VLM13580T-2R2M-D1 Weight	Contact Us
Replacement Part Number	VLM13580T-2R2M-D1-FT
