Home / Products / Isolators / Optoisolators - Logic Output / TLP2261(D4-TP4,E

TLP2261(D4-TP4,E Image

Toshiba Semiconductor and Storage TLP2261(D4-TP4,E

MFG Part Number
TLP2261(D4-TP4,E
Available Quantity
69790 Pieces
Reference Price
USD 0.713896
Our Price
We have a big discount, please contact us
Shipping Date
We can ship out today
Manufacturer
Toshiba Semiconductor and Storage
Brief Description
- HIGH SPEED LOGIC OUTPUT OPTOCOUP
Lead Free Status / RoHS Status
RoHS Compliant (Lead Free)
Moisture Sensitivity Level (MSL)
1 (Unlimited)
Date Code (D/C)
New
Product Category
Optoisolators - Logic Output
Stock Resource
Franchised Distributor
Warranty
360 days quality guarantee
Datasheet
TLP2261(D4-TP4,E.pdf
TLP2261(D4-TP4,E Image

Request Quotation for TLP2261(D4-TP4,E

Company Name
Contact Person
Phone Number
Address
Email
Message

TLP2261(D4-TP4,E Specifications

Manufacturer Part Number TLP2261(D4-TP4,E
Future Part Number FT-TLP2261(D4-TP4,E
SPQ / MOQ Contact Us
Packing Material Reel/Tray/Tube/Others
Series -
TLP2261(D4-TP4,E Status (Lifecycle) In Stock
Part Status Active
Number of Channels 2
Inputs - Side 1/Side 2 2/0
Voltage - Isolation 5000Vrms
Common Mode Transient Immunity (Min) 20kV/µs
Input Type DC
Output Type Push-Pull, Totem Pole
Current - Output / Channel 10mA
Data Rate 15MBd
Propagation Delay tpLH / tpHL (Max) 80ns, 80ns
Rise / Fall Time (Typ) 3ns, 3ns
Voltage - Forward (Vf) (Typ) 1.5V
Current - DC Forward (If) (Max) 10mA
Voltage - Supply 2.7V ~ 5.5V
Operating Temperature -40°C ~ 125°C
Mounting Type Surface Mount
Package / Case 8-SOIC (0.295", 7.50mm Width)
Supplier Device Package 8-SOIC
Country of Origin USA/JAPAN/MALAYSIA/MEXICO/CN
TLP2261(D4-TP4,E Weight Contact Us
Replacement Part Number TLP2261(D4-TP4,E-FT
