E-Switch TL1105JAF160Q/1D

Name: TL1105JAF160Q/1D
Brand: E-Switch
SKU: TL1105JAF160Q/1D
Price: 0.460784 USD
Availability: InStock
Rating: 4.8 (747 reviews)

MFG Part Number: TL1105JAF160Q/1D

Available Quantity: 26020 Pieces

Reference Price: USD 0.460784

Our Price: We have a big discount, please contact us

Shipping Date: We can ship out today

Manufacturer: E-Switch

Brief Description: TL1105 SWITCH TACTILE SPST-NO 0.05A 12V

Lead Free Status / RoHS Status: RoHS Compliant (Lead Free)

Moisture Sensitivity Level (MSL): 1 (Unlimited)

Date Code (D/C): New

Product Category: Tactile Switches

Stock Resource: Franchised Distributor

Warranty: 360 days quality guarantee

Datasheet: TL1105JAF160Q/1D.pdf

TL1105JAF160Q/1D Specifications

Manufacturer Part Number	TL1105JAF160Q/1D
Future Part Number	FT-TL1105JAF160Q/1D
SPQ / MOQ	Contact Us
Packing Material	Reel/Tray/Tube/Others
Series	TL1105
TL1105JAF160Q/1D Status (Lifecycle)	In Stock
Part Status	Active
Circuit	SPST-NO
Switch Function	Off-Mom
Contact Rating @ Voltage	0.05A @ 12VDC
Actuator Type	Square Button
Mounting Type	Through Hole, Right Angle
Actuator Height off PCB, Vertical	-
Actuator Length, Right Angle	12.00mm
Actuator Orientation	Side Actuated
Termination Style	PC Pin
Outline	7.20mm x 6.50mm
Illumination	Non-Illuminated
Illumination Type, Color	-
Illumination Voltage (Nominal)	-
Operating Force	160gf
Ingress Protection	-
Features	-
Operating Temperature	-20°C ~ 70°C
Country of Origin	USA/JAPAN/MALAYSIA/MEXICO/CN
TL1105JAF160Q/1D Weight	Contact Us
Replacement Part Number	TL1105JAF160Q/1D-FT
