QT Brightek (QTB) QT1010T1-W
- MFG Part Number
- QT1010T1-W
- Available Quantity
- 79860 Pieces
- Reference Price
- USD 0.224
- Our Price
- We have a big discount, please contact us
- Shipping Date
- We can ship out today
- Manufacturer
- QT Brightek (QTB)
- Brief Description
- - LONG CREEPAGE MINI-FLAT PACKAGE
- Lead Free Status / RoHS Status
- RoHS Compliant (Lead Free)
- Moisture Sensitivity Level (MSL)
- 1 (Unlimited)
- Date Code (D/C)
- New
- Product Category
- Optoisolators - Transistor, Photovoltaic Output
- Stock Resource
- Franchised Distributor
- Warranty
- 360 days quality guarantee
- Datasheet
- QT1010T1-W.pdf
QT1010T1-W Specifications
| Manufacturer Part Number | QT1010T1-W |
|---|---|
| Future Part Number | FT-QT1010T1-W |
| SPQ / MOQ | Contact Us |
| Packing Material | Reel/Tray/Tube/Others |
| Series | - |
| QT1010T1-W Status (Lifecycle) | In Stock |
| Part Status | Active |
| Number of Channels | 1 |
| Voltage - Isolation | 5000Vrms |
| Current Transfer Ratio (Min) | 50% @ 5mA |
| Current Transfer Ratio (Max) | 600% @ 5mA |
| Turn On / Turn Off Time (Typ) | 4.8µs, 4.2µs |
| Rise / Fall Time (Typ) | 2.8µs, 4µs |
| Input Type | DC |
| Output Type | Transistor |
| Voltage - Output (Max) | 80V |
| Current - Output / Channel | 50mA |
| Voltage - Forward (Vf) (Typ) | 1.42V |
| Current - DC Forward (If) (Max) | 50mA |
| Vce Saturation (Max) | 400mV |
| Operating Temperature | -55°C ~ 125°C |
| Mounting Type | Surface Mount |
| Package / Case | 6-SOIC (0.295", 7.50mm Width), 4 Leads |
| Supplier Device Package | 4-Mini-Flat |
| Country of Origin | USA/JAPAN/MALAYSIA/MEXICO/CN |
| QT1010T1-W Weight | Contact Us |
| Replacement Part Number | QT1010T1-W-FT |
