Home / Products / Isolators / Optoisolators - Transistor, Photovoltaic Output / PS2706-1-A
Renesas Electronics America PS2706-1-A
- MFG Part Number
- PS2706-1-A
- Available Quantity
- 84790 Pieces
- Reference Price
- USD 1.408
- Our Price
- We have a big discount, please contact us
- Shipping Date
- We can ship out today
- Manufacturer
- Renesas Electronics America
- Brief Description
- NEPOC OPTOISOLATOR 3.75KV DARL 4SMD
- Lead Free Status / RoHS Status
- RoHS Compliant (Lead Free)
- Moisture Sensitivity Level (MSL)
- 1 (Unlimited)
- Date Code (D/C)
- New
- Product Category
- Optoisolators - Transistor, Photovoltaic Output
- Stock Resource
- Franchised Distributor
- Warranty
- 360 days quality guarantee
- Datasheet
- PS2706-1-A.pdf
PS2706-1-A Specifications
| Manufacturer Part Number | PS2706-1-A |
|---|---|
| Future Part Number | FT-PS2706-1-A |
| SPQ / MOQ | Contact Us |
| Packing Material | Reel/Tray/Tube/Others |
| Series | NEPOC |
| PS2706-1-A Status (Lifecycle) | In Stock |
| Part Status | Active |
| Number of Channels | 1 |
| Voltage - Isolation | 3750Vrms |
| Current Transfer Ratio (Min) | 200% @ 1mA |
| Current Transfer Ratio (Max) | - |
| Turn On / Turn Off Time (Typ) | - |
| Rise / Fall Time (Typ) | 200µs, 200µs |
| Input Type | AC, DC |
| Output Type | Darlington |
| Voltage - Output (Max) | 40V |
| Current - Output / Channel | 200mA |
| Voltage - Forward (Vf) (Typ) | 1.1V |
| Current - DC Forward (If) (Max) | 50mA |
| Vce Saturation (Max) | 1V |
| Operating Temperature | -55°C ~ 100°C |
| Mounting Type | Surface Mount |
| Package / Case | 4-SMD, Gull Wing |
| Supplier Device Package | 4-SOP |
| Country of Origin | USA/JAPAN/MALAYSIA/MEXICO/CN |
| PS2706-1-A Weight | Contact Us |
| Replacement Part Number | PS2706-1-A-FT |
