Pulse Electronics Power PA4307.223NLT

Name: PA4307.223NLT
Brand: Pulse Electronics Power
SKU: PA4307.223NLT
Price: 0.37408 USD
Availability: InStock
Rating: 4.6 (598 reviews)

MFG Part Number: PA4307.223NLT

Available Quantity: 90350 Pieces

Reference Price: USD 0.37408

Our Price: We have a big discount, please contact us

Shipping Date: We can ship out today

Manufacturer: Pulse Electronics Power

Brief Description: PA4307.XXXNL FIXED Inductors 22UH 2A 345 MOHM SMD

Lead Free Status / RoHS Status: RoHS Compliant (Lead Free)

Moisture Sensitivity Level (MSL): 1 (Unlimited)

Date Code (D/C): New

Product Category: Fixed Inductors

Stock Resource: Franchised Distributor

Warranty: 360 days quality guarantee

Datasheet: PA4307.223NLT.pdf

Request Quotation for PA4307.223NLT

Company Name

Contact Person

Phone Number

Address

Email

Message

PA4307.223NLT Specifications

Manufacturer Part Number	PA4307.223NLT
Future Part Number	FT-PA4307.223NLT
SPQ / MOQ	Contact Us
Packing Material	Reel/Tray/Tube/Others
Series	PA4307.XXXNL
PA4307.223NLT Status (Lifecycle)	In Stock
Part Status	Active
Type	Wirewound
Material - Core	-
Inductance	22µH
Tolerance	±20%
Current Rating	2A
Current - Saturation	-
Shielding	Unshielded
DC Resistance (DCR)	345 mOhm Max
Q @ Freq	-
Frequency - Self Resonant	-
Ratings	-
Operating Temperature	-40°C ~ 125°C
Inductance Frequency - Test	100kHz
Features	-
Mounting Type	Surface Mount
Package / Case	Nonstandard
Supplier Device Package	-
Size / Dimension	0.287" L x 0.287" W (7.30mm x 7.30mm)
Height - Seated (Max)	0.138" (3.50mm)
Country of Origin	USA/JAPAN/MALAYSIA/MEXICO/CN
PA4307.223NLT Weight	Contact Us
Replacement Part Number	PA4307.223NLT-FT
