Microchip Technology MCP14A0152T-E/MAY
- MFG Part Number
- MCP14A0152T-E/MAY
- Available Quantity
- 37610 Pieces
- Reference Price
- USD 0.4532
- Our Price
- We have a big discount, please contact us
- Shipping Date
- We can ship out today
- Manufacturer
- Microchip Technology
- Brief Description
- - IC MOSFET DVR 1.5A SINGLE 2X2 QF
- Lead Free Status / RoHS Status
- RoHS Compliant (Lead Free)
- Moisture Sensitivity Level (MSL)
- 1 (Unlimited)
- Date Code (D/C)
- New
- Product Category
- PMIC - Gate Drivers
- Stock Resource
- Franchised Distributor
- Warranty
- 360 days quality guarantee
- Datasheet
- MCP14A0152T-E/MAY.pdf
MCP14A0152T-E/MAY Specifications
| Manufacturer Part Number | MCP14A0152T-E/MAY |
|---|---|
| Future Part Number | FT-MCP14A0152T-E/MAY |
| SPQ / MOQ | Contact Us |
| Packing Material | Reel/Tray/Tube/Others |
| Series | - |
| MCP14A0152T-E/MAY Status (Lifecycle) | In Stock |
| Part Status | Active |
| Driven Configuration | High-Side or Low-Side |
| Channel Type | Single |
| Number of Drivers | 1 |
| Gate Type | N-Channel, P-Channel MOSFET |
| Voltage - Supply | 4.5V ~ 18V |
| Logic Voltage - VIL, VIH | 0.8V, 2V |
| Current - Peak Output (Source, Sink) | 1.5A, 1.5A |
| Input Type | Non-Inverting |
| High Side Voltage - Max (Bootstrap) | - |
| Rise / Fall Time (Typ) | 11.5ns, 10ns |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 6-VDFN Exposed Pad |
| Supplier Device Package | 6-DFN (2x2) |
| Country of Origin | USA/JAPAN/MALAYSIA/MEXICO/CN |
| MCP14A0152T-E/MAY Weight | Contact Us |
| Replacement Part Number | MCP14A0152T-E/MAY-FT |
