Home / Products / Switches / Rocker Switches / M2023TJW01-FC-3A-CE

NKK Switches M2023TJW01-FC-3A-CE

Name: M2023TJW01-FC-3A-CE
Brand: NKK Switches
SKU: M2023TJW01-FC-3A-CE
Price: 7.256 USD
Availability: InStock
Rating: 5.0 (807 reviews)

MFG Part Number: M2023TJW01-FC-3A-CE

Available Quantity: 62290 Pieces

Reference Price: USD 7.256

Our Price: We have a big discount, please contact us

Shipping Date: We can ship out today

Manufacturer: NKK Switches

Brief Description: M SWITCH ROCKER DPDT 6A 125V

Lead Free Status / RoHS Status: RoHS Compliant (Lead Free)

Moisture Sensitivity Level (MSL): 1 (Unlimited)

Date Code (D/C): New

Product Category: Rocker Switches

Stock Resource: Franchised Distributor

Warranty: 360 days quality guarantee

Datasheet: M2023TJW01-FC-3A-CE.pdf

Request Quotation for M2023TJW01-FC-3A-CE

Company Name

Contact Person

Phone Number

Address

Email

Message

M2023TJW01-FC-3A-CE Specifications

Manufacturer Part Number	M2023TJW01-FC-3A-CE
Future Part Number	FT-M2023TJW01-FC-3A-CE
SPQ / MOQ	Contact Us
Packing Material	Reel/Tray/Tube/Others
Series	M
M2023TJW01-FC-3A-CE Status (Lifecycle)	In Stock
Part Status	Active
Circuit	DPDT
Switch Function	On-Off-On
Current Rating	6A (AC), 3A (DC)
Voltage Rating - AC	125V
Voltage Rating - DC	30V
Actuator Type	Concave (Standard V) - Illuminated
Color - Actuator/Cap	Red
Actuator Marking	No Marking
Illumination Type, Color	LED, Red/Yellow
Illumination Voltage (Nominal)	2 VDC
Mounting Type	Panel Mount, Snap-In
Termination Style	Solder Lug
Ingress Protection	-
Features	Epoxy Sealed Terminals
Panel Cutout Dimensions	Rectangular - 18.70mm x 15.90mm
Operating Temperature	-30°C ~ 85°C
Country of Origin	USA/JAPAN/MALAYSIA/MEXICO/CN
M2023TJW01-FC-3A-CE Weight	Contact Us
Replacement Part Number	M2023TJW01-FC-3A-CE-FT
