Microsemi Corporation JANTX1N6511

Name: JANTX1N6511
Brand: Microsemi Corporation
SKU: JANTX1N6511
Price: 230.84 USD
Availability: InStock
Rating: 4.7 (578 reviews)

MFG Part Number: JANTX1N6511

Available Quantity: 48510 Pieces

Reference Price: USD 230.84

Our Price: We have a big discount, please contact us

Shipping Date: We can ship out today

Manufacturer: Microsemi Corporation

Brief Description: Military, MIL-PRF-19500/4 DIODE ARRAY GP 75V 300MA AXIAL

Lead Free Status / RoHS Status: RoHS Compliant (Lead Free)

Moisture Sensitivity Level (MSL): 1 (Unlimited)

Date Code (D/C): New

Product Category: Diodes - Rectifiers - Arrays

Stock Resource: Franchised Distributor

Warranty: 360 days quality guarantee

Datasheet: JANTX1N6511.pdf

Request Quotation for JANTX1N6511

Company Name

Contact Person

Phone Number

Address

Email

Message

JANTX1N6511 Specifications

Manufacturer Part Number	JANTX1N6511
Future Part Number	FT-JANTX1N6511
SPQ / MOQ	Contact Us
Packing Material	Reel/Tray/Tube/Others
Series	Military, MIL-PRF-19500/4
JANTX1N6511 Status (Lifecycle)	In Stock
Part Status	Active
Diode Configuration	7 Independent
Diode Type	Standard
Voltage - DC Reverse (Vr) (Max)	75V
Current - Average Rectified (Io) (per Diode)	300mA (DC)
Voltage - Forward (Vf) (Max) @ If	1V @ 100mA
Speed	Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr)	10ns
Current - Reverse Leakage @ Vr	100nA @ 40V
Operating Temperature - Junction	-
Mounting Type	Through Hole
Package / Case	14-CDIP (0.300", 7.62mm)
Supplier Device Package	14-CDIP
Country of Origin	USA/JAPAN/MALAYSIA/MEXICO/CN
JANTX1N6511 Weight	Contact Us
Replacement Part Number	JANTX1N6511-FT
