Home / Products / Inductors, Coils, Chokes / Fixed Inductors / FP1005R2-R22-R
Eaton - Electronics Division FP1005R2-R22-R
- MFG Part Number
- FP1005R2-R22-R
- Available Quantity
- 73950 Pieces
- Reference Price
- USD 0.70784
- Our Price
- We have a big discount, please contact us
- Shipping Date
- We can ship out today
- Manufacturer
- Eaton - Electronics Division
- Brief Description
- FLAT-PAC, FP1005 FIXED Inductors 220NH 50A 0.47 MOHM
- Lead Free Status / RoHS Status
- RoHS Compliant (Lead Free)
- Moisture Sensitivity Level (MSL)
- 1 (Unlimited)
- Date Code (D/C)
- New
- Product Category
- Fixed Inductors
- Stock Resource
- Franchised Distributor
- Warranty
- 360 days quality guarantee
- Datasheet
- FP1005R2-R22-R.pdf
FP1005R2-R22-R Specifications
| Manufacturer Part Number | FP1005R2-R22-R |
|---|---|
| Future Part Number | FT-FP1005R2-R22-R |
| SPQ / MOQ | Contact Us |
| Packing Material | Reel/Tray/Tube/Others |
| Series | FLAT-PAC, FP1005 |
| FP1005R2-R22-R Status (Lifecycle) | In Stock |
| Part Status | Active |
| Type | Wirewound |
| Material - Core | Ferrite |
| Inductance | 220nH |
| Tolerance | ±10% |
| Current Rating | 50A |
| Current - Saturation | 33A |
| Shielding | Unshielded |
| DC Resistance (DCR) | 0.47 mOhm |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | - |
| Operating Temperature | -40°C ~ 125°C |
| Inductance Frequency - Test | 100kHz |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Supplier Device Package | - |
| Size / Dimension | 0.402" L x 0.276" W (10.20mm x 7.00mm) |
| Height - Seated (Max) | 0.195" (4.95mm) |
| Country of Origin | USA/JAPAN/MALAYSIA/MEXICO/CN |
| FP1005R2-R22-R Weight | Contact Us |
| Replacement Part Number | FP1005R2-R22-R-FT |
