STMicroelectronics ESDA24P140-1U3M

Name: ESDA24P140-1U3M
Brand: STMicroelectronics
SKU: ESDA24P140-1U3M
Price: 0.13508 USD
Availability: InStock
Rating: 4.6 (485 reviews)

MFG Part Number: ESDA24P140-1U3M

Available Quantity: 37880 Pieces

Reference Price: USD 0.13508

Our Price: We have a big discount, please contact us

Shipping Date: We can ship out today

Manufacturer: STMicroelectronics

Brief Description: ESDA, TRANSIL™ HIGH POWER TRANSIENT VOLTAGE SUP

Lead Free Status / RoHS Status: RoHS Compliant (Lead Free)

Moisture Sensitivity Level (MSL): 1 (Unlimited)

Date Code (D/C): New

Product Category: TVS - Diodes

Stock Resource: Franchised Distributor

Warranty: 360 days quality guarantee

Datasheet: ESDA24P140-1U3M.pdf

Request Quotation for ESDA24P140-1U3M

Company Name

Contact Person

Phone Number

Address

Email

Message

ESDA24P140-1U3M Specifications

Manufacturer Part Number	ESDA24P140-1U3M
Future Part Number	FT-ESDA24P140-1U3M
SPQ / MOQ	Contact Us
Packing Material	Reel/Tray/Tube/Others
Series	ESDA, TRANSIL™
ESDA24P140-1U3M Status (Lifecycle)	In Stock
Part Status	Active
Type	Zener
Unidirectional Channels	2
Bidirectional Channels	-
Voltage - Reverse Standoff (Typ)	22V (Max)
Voltage - Breakdown (Min)	22.7V
Voltage - Clamping (Max) @ Ipp	29.5V
Current - Peak Pulse (10/1000µs)	10A
Power - Peak Pulse	330W
Power Line Protection	No
Applications	General Purpose
Capacitance @ Frequency	-
Operating Temperature	-55°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Package / Case	3-UDFN Exposed Pad
Supplier Device Package	3-QFN (2x2)
Country of Origin	USA/JAPAN/MALAYSIA/MEXICO/CN
ESDA24P140-1U3M Weight	Contact Us
Replacement Part Number	ESDA24P140-1U3M-FT
