Eaton - Electronics Division CTX33-3A-R

Name: CTX33-3A-R
Brand: Eaton - Electronics Division
SKU: CTX33-3A-R
Availability: InStock
Rating: 5.0 (601 reviews)

MFG Part Number: CTX33-3A-R

Available Quantity: 71460 Pieces

Reference Price: USD 0

Our Price: We have a big discount, please contact us

Shipping Date: We can ship out today

Manufacturer: Eaton - Electronics Division

Brief Description: OCTA-PAC® PLUS INDUCT ARRAY 2 COIL 33.71UH SMD

Lead Free Status / RoHS Status: RoHS Compliant (Lead Free)

Moisture Sensitivity Level (MSL): 1 (Unlimited)

Date Code (D/C): New

Product Category: Arrays, Signal Transformers

Stock Resource: Franchised Distributor

Warranty: 360 days quality guarantee

Datasheet: CTX33-3A-R.pdf

Request Quotation for CTX33-3A-R

Company Name

Contact Person

Phone Number

Address

Email

Message

CTX33-3A-R Specifications

Manufacturer Part Number	CTX33-3A-R
Future Part Number	FT-CTX33-3A-R
SPQ / MOQ	Contact Us
Packing Material	Reel/Tray/Tube/Others
Series	OCTA-PAC® PLUS
CTX33-3A-R Status (Lifecycle)	In Stock
Part Status	Obsolete
Number of Coils	2
Inductance - Connected In Parallel	33.71µH
Inductance - Connected In Series	134.8µH
Tolerance	±25%
Current Rating - Parallel	1.93A
Current Rating - Series	960mA
Current Saturation - Parallel	1.61A
Current Saturation - Series	800mA
DC Resistance (DCR) - Parallel	112 mOhm Max
DC Resistance (DCR) - Series	449 mOhm Max
Shielding	Unshielded
Ratings	-
Operating Temperature	-40°C ~ 85°C
Mounting Type	Surface Mount
Package / Case	Nonstandard
Size / Dimension	0.550" L x 0.550" W (13.97mm x 13.97mm)
Height	0.190" (4.83mm)
Country of Origin	USA/JAPAN/MALAYSIA/MEXICO/CN
CTX33-3A-R Weight	Contact Us
Replacement Part Number	CTX33-3A-R-FT
