Panasonic Electronic Components CNB1301

Name: CNB1301
Brand: Panasonic Electronic Components
SKU: CNB1301
Availability: InStock
Rating: 4.8 (529 reviews)

MFG Part Number: CNB1301

Available Quantity: 11370 Pieces

Reference Price: USD 0

Our Price: We have a big discount, please contact us

Shipping Date: We can ship out today

Manufacturer: Panasonic Electronic Components

Brief Description: - SENSOR OPTO TRANS 2.5MM REFL PCB

Lead Free Status / RoHS Status: RoHS Compliant (Lead Free)

Moisture Sensitivity Level (MSL): 1 (Unlimited)

Date Code (D/C): New

Product Category: Optical Sensors - Reflective - Analog Output

Stock Resource: Franchised Distributor

Warranty: 360 days quality guarantee

Datasheet: CNB1301.pdf

CNB1301 Specifications

Manufacturer Part Number	CNB1301
Future Part Number	FT-CNB1301
SPQ / MOQ	Contact Us
Packing Material	Reel/Tray/Tube/Others
Series	-
CNB1301 Status (Lifecycle)	In Stock
Part Status	Obsolete
Sensing Distance	0.098" (2.5mm)
Sensing Method	Reflective
Voltage - Collector Emitter Breakdown (Max)	30V
Current - Collector (Ic) (Max)	20mA
Current - DC Forward (If) (Max)	50mA
Output Type	Phototransistor
Response Time	20µs, 20µs
Mounting Type	Through Hole
Package / Case	PCB Mount
Country of Origin	USA/JAPAN/MALAYSIA/MEXICO/CN
CNB1301 Weight	Contact Us
Replacement Part Number	CNB1301-FT
