Home / Products / Filters / Common Mode Chokes / CM7560-186
Manufacturer Part Number | CM7560-186 |
---|---|
Future Part Number | FT-CM7560-186 |
SPQ / MOQ | Contact Us |
Packing Material | Reel/Tray/Tube/Others |
Series | CM7560 |
CM7560-186 Status (Lifecycle) | In Stock |
Part Status | Active |
Filter Type | - |
Number of Lines | 2 |
Impedance @ Frequency | - |
Inductance @ Frequency | 18mH @ 1kHz |
Current Rating (Max) | 550mA |
DC Resistance (DCR) (Max) | 1.3 Ohm |
Voltage Rating - DC | - |
Voltage Rating - AC | - |
Operating Temperature | -55°C ~ 125°C |
Ratings | - |
Approvals | - |
Features | - |
Mounting Type | Through Hole |
Size / Dimension | 1.071" L x 0.858" W (27.20mm x 21.80mm) |
Height (Max) | 0.861" (21.86mm) |
Package / Case | Vertical, 4 PC Pin |
Country of Origin | USA/JAPAN/MALAYSIA/MEXICO/CN |
CM7560-186 Weight | Contact Us |
Replacement Part Number | CM7560-186-FT |
