Home / Products / Optoelectronics / LED Indication - Discrete / CL-505S-X-SD-T
Citizen CL-505S-X-SD-T
- MFG Part Number
- CL-505S-X-SD-T
- Available Quantity
- 40800 Pieces
- Reference Price
- USD 0.18544
- Our Price
- We have a big discount, please contact us
- Shipping Date
- We can ship out today
- Manufacturer
- Citizen
- Brief Description
- CL-505S LED TRI TOP FIRING 1.0 X 1.0
- Lead Free Status / RoHS Status
- RoHS Compliant (Lead Free)
- Moisture Sensitivity Level (MSL)
- 1 (Unlimited)
- Date Code (D/C)
- New
- Product Category
- LED Indication - Discrete
- Stock Resource
- Franchised Distributor
- Warranty
- 360 days quality guarantee
- Datasheet
- CL-505S-X-SD-T.pdf
CL-505S-X-SD-T Specifications
| Manufacturer Part Number | CL-505S-X-SD-T |
|---|---|
| Future Part Number | FT-CL-505S-X-SD-T |
| SPQ / MOQ | Contact Us |
| Packing Material | Reel/Tray/Tube/Others |
| Series | CL-505S |
| CL-505S-X-SD-T Status (Lifecycle) | In Stock |
| Part Status | Active |
| Color | Red, Green, Blue (RGB) |
| Configuration | Common Anode |
| Lens Color | - |
| Lens Transparency | - |
| Millicandela Rating | 40mcd Red, 220mcd Green, 65mcd Blue |
| Lens Style | Square with Flat Top |
| Lens Size | 1.00mm |
| Voltage - Forward (Vf) (Typ) | 1.85V Red, 2.7V Green, 2.75V Blue |
| Current - Test | 5mA Red, 5mA Green, 5mA Blue |
| Viewing Angle | - |
| Mounting Type | Surface Mount |
| Wavelength - Dominant | 615nm Red, 530nm Green, 470nm Blue |
| Wavelength - Peak | - |
| Features | - |
| Package / Case | 0404 (1010 Metric) |
| Supplier Device Package | - |
| Size / Dimension | 1.00mm L x 1.00mm W |
| Height (Max) | 0.26mm |
| Country of Origin | USA/JAPAN/MALAYSIA/MEXICO/CN |
| CL-505S-X-SD-T Weight | Contact Us |
| Replacement Part Number | CL-505S-X-SD-T-FT |
